Foundationless Jib Crane



Lub hauv paus tsis muaj jib crane yog hauv pem teb - mounted, freestanding lifting system rau localized tuav hauv cov chaw uas twb muaj lawm. Nws fastens mus rau ib tug certified reinforced pob zeb slab ntawm post-installed anchors. Tsis muaj excavation los yog cais poured crane foundation yuav tsum ua ntej ntawm qhov chaw installation.

Lub kaw lus no haum rau lub teeb-lub luag haujlwm nqa cov haujlwm rau cov chaw nres tsheb sib dhos, lub tshuab thauj khoom, vuam bays, thaj chaw tu thiab cov kab ntim khoom. Nws lub hauv paus loj loj faib cov lifting rog los ntawm cov slab uas twb muaj lawm thaum lub boom muab ib tug txhais tuav lub vojvoog ze rau qhov chaw ua hauj lwm.

Lub hauv paus tsis muaj jib crane tsis tshem tawm cov kev xav tau ntawm cov qauv. Kev ntsuam xyuas ntawm qhov chaw yuav tsum npog cov pob zeb uas twb muaj lawm, steel reinforcement, anchoring zone thiab tag nrho cov kev txhawb nqa. Kev ntsuam xyuas yuav siv sij hawm mus rau hauv tus account lub hom phiaj load peev xwm, boom ncav cuag, hoist hnyav raws li lub luag hauj lwm-cycle yuav tsum tau.







Lub crane muaj xws li steel mast, reinforced puag los ua ke, boom, slewing lub taub hau, trolley txoj kev, thiab ncej- nruab anchoring system. Gussets stiffen lub mast- rau- puag kev sib txuas hauv qab nqa thiab slewing loads. Los ntawm txhais tes los yog lub zog sib hloov, kev sib hloov nres, boom locks, thiab cov khoom siv hoisting tau raug xaiv raws li daim ntawv thov.





Parameter	Hom Configuration
Rated peev	Lub teeb- lub luag haujlwm nqa, feem ntau txog li 1,000 kg; Lub peev xwm kawg yog nyob ntawm qhov kev teeb tsa crane thiab kev txheeb xyuas slab.
Boom span	Xaiv ib ncig ntawm thaj chaw ua haujlwm uas yuav tsum tau ua thiab tso cai overturning load.
Hauv qab -boom qhov siab	Haum rau qhov siab load, nuv mus ncig, hoist headroom, thiab clearance.
Kev sib hloov	Mus txog 360 degrees qhov twg xaiv tsim thiab qhov chaw tshem tawm daim ntawv tso cai.
Kev teeb tsa	Tshaj tawm -ntsuas anchors rau ntawm qhov tsim nyog cov pob zeb ua pob zeb; tsis muaj kev tshwj xeeb ua ntej-poured crane footing.

Qhov kawg qhov ntev, muaj peev xwm, hoist tuag qhov hnyav, thiab thauj tog rau nkoj yuav tsum tau tshuaj xyuas raws li ib rooj plaub.





Ob qho tib si tsim yog dawbstanding jib cranes, tab sis lawv siv cov txheej txheem sib txawv. Lub hauv paus tsis muaj jib crane yog ntsia rau ntawm ib qho uas twb muaj lawm, engineered reinforced pob zeb slab siv lub hauv paus loj thiab ncej-ntsuas anchors. Nws yog npaj rau lub teeb - lub luag hauj lwm nqa qhov twg lub slab yog haum thiab ib tug tshwj xeeb embedded footing yog tsis yuav tsum tau.

Ib tug ncej jib crane feem ntau yog xaiv rau lub peev xwm siab dua, ncua sij hawm ntev, lub luag haujlwm hnyav, lossis cov xwm txheej uas yuav tsum tau muaj lub hauv paus muaj zog ntxiv. Nws tsis tuaj yeem hloov pauv nrog lub hauv paus tsis muaj jib crane tsuas yog vim tias ob qho tib si muaj hauv pem teb -mounted mast.







Lub crane yuav tsum tsuas yog mounted rau ntawm ib qho kev pom zoo cov pob zeb ua vaj tse. Ua ntej installation, paub meej tias:

• Slab thickness, reinforcement, mob, thiab kev txhawb nqa hauv qab lub slab.
• Tsis muaj cov kab nrib pleb tsis zoo, cov pob qij txha nthuav dav, voids, trenches, lossis cov npoo tsis txhawb nqa hauv thaj chaw thauj tog rau nkoj.
• Anchor hom, embedment, spacing, thiab ntug nrug rau qhov project load case.
• Clearance rau boom kev sib hloov, thauj mus los, tswj, thiab tus neeg teb xov tooj nkag.
• Sab hauv lossis sab nraum zoov raug, tiv thaiv corrosion, thiab kev ua raws cai hauv zos.

Tom qab kev teeb tsa, lub crane thiab anchoring cheeb tsam yuav tsum tau soj ntsuam thiab kuaj pov thawj raws li qhov tsim nyog yuav tsum ua ua ntej ua haujlwm.





Foundationless jib cranes pab cov chaw nrog cov haujlwm ruaj khov uas hu rau kev nqa luv luv, tshem tawm qhov xav tau rau lub hom phiaj tsim crane footing. Cov khoom siv feem ntau npog cov khoom sib dhos, tshuab sib dhos, vuam ua haujlwm, kev ua haujlwm tu, kev thauj khoom, ntim khoom thiab chaw ua haujlwm retrofits.

Txhawm rau ua kom tiav chav tsev xaiv kom zoo, muab tag nrho cov tsis suav nrog cov ntsuas ntsuas (hoist thiab nqa cov khoom txuas nrog), yuav tsum tau boom ncua, hauv qab-boom qhov siab, lifting zaus, kev sib hloov specifications, qhov chaw ua hauj lwm ib puag ncig thiab muaj cov ntaub ntawv slab.







Dab tsi yog lub hauv paus tsis muaj jib crane?

Nws yog hauv pem teb -mounted freestanding jib crane anchored mus rau ib tug uas twb muaj lawm tsim nyog reinforced pob zeb slab. Nws tsis tas yuav muaj qhov sib cais ua ntej - nchuav lossis ua ntej - crane foundation.

Puas yog lub hauv paus tsis muaj jib crane xav tau lub pob zeb hauv pem teb?

Yog lawm. Nws yuav tsum muaj cov pob zeb ua kom muaj zog muaj peev xwm nqa tau cov kab ntsug, sab nraub qaum, thiab tig rov qab ntawm lub crane. Pem teb thickness ib leeg tsis paub meej tias haum; kev txhim kho, tawg, pob qij txha, thauj tog rau nkoj, thiab kev txhawb nqa yuav tsum tau kuaj xyuas.

Nws txawv ntawm tus ncej jib crane li cas?

Ib tug ncej jib crane feem ntau siv lub hauv paus tshwj xeeb uas muaj zog ntxiv. Ib lub hauv paus tsis muaj jib crane tso siab rau cov ntawv pov thawj uas twb muaj lawm thiab tshaj tawm -ntsuas cov thauj tog rau nkoj, ua kom nws haum rau sib dua - lub luag haujlwm nqa thiab rov ua haujlwm dua.

Nws puas tuaj yeem ntsia tau ze ntawm qhov sib koom hauv pem teb lossis tawg?

Tsis yog tsis muaj kev pom zoo engineering. Cov kab nrib pleb, cov pob qij txha nthuav dav, cov npoo npoo, cov trenches, thiab cov voids tuaj yeem txo cov thauj tog rau nkoj- cheeb tsam muaj peev xwm thiab yuav tsum tau ntsuas ua ntej qhov chaw hauv paus tau lees paub.

Puas yog lub hauv paus tsis muaj jib crane tig 360 degrees?

Yog, qhov twg xaiv crane configuration, ib puag ncig clearance, thiab lub hwj chim los yog huab cua routing pub tag nrho kev sib hloov. Kev sib hloov nres tuaj yeem siv tau thaum lub sijhawm ua haujlwm tau hais tseg.

Lub crane puas tuaj yeem hloov tau?

Tau, raug rau qhov kev ntsuam xyuas tshiab thiab thauj tog rau nkoj ntawm qhov chaw tom ntej. Cov anchors uas twb muaj lawm yuav tsum tsis txhob xav tias tsim nyog rau rov siv dua.





Lub hauv paus tsis muaj jib crane txo cov kev ua haujlwm hauv pej xeem cuam tshuam nrog kev mob siab rau crane footing thaum khaws cov qauv kev qhuab qhia uas yuav tsum tau ua kom muaj kev nyab xeeb. Nws yog qhov kev xaiv ua tau zoo thaum cov pob zeb uas twb muaj lawm tuaj yeem raug txheeb xyuas tau rau qhov kev xaiv muaj peev xwm, ncav cuag, qhov chaw nres tsheb, thiab kev ua haujlwm.
