Metallurgy Electric Hoist
Txheej txheem cej luam
Hluav taws xob hoist rau metallurgy yog metallurgy crane tsuas yog siv los nqa cov hlau molten. Nws lub peev xwm nqa tau tsawg dua lossis sib npaug li 20m. qhov chaw ua haujlwm kub yog -10 degree ~ 60 degree thiab txheeb ze av noo tsawg dua 50 feem pua hauv qhov ntsuas kub ntawm 40 feem pua. Hluav taws xob hoist muaj ntau yam kev tiv thaiv xws li ob chav braking, ob chav sib nrug, tshav kub rwb thaiv tsev phaj thiab lwm yam. Metallurgy hluav taws xob hoist yog ib lub teeb zoo tshaj plaws metallurgy hoisting khoom uas tuaj yeem siv ua ke nrog LDY hom metallurgy ib leeg girder crane thiab tuaj yeem ntsia tau rau hauv kev cob qhia kev ncua kev tsheb ciav hlau siv tus kheej. Tsim thiab tsim khoom ntawm metallurgy hluav taws xob hoist ua tau raws li qhov xav tau ntawm AQSIQ Doc#(2007)375. Lwm yam xwm txheej uas nqa fusion cov khoom tsis yog xim hlau lossis cov hlau kub kuj tuaj yeem xa mus.
Nta
● Compact qauv, lub teeb yuag, nyab xeeb thiab txhim khu kev qha;
● Dav siv thiab sib hloov ntawm cov khoom;
● Lifting muaj zog, txij nkawm yooj yim;
● Kev ua haujlwm yooj yim, nqa ruaj khov.
Tuam Tshoj nto moo YH Metallugy Electric Hoist Kub Muag
Daim duab piav qhia
Technical Parameter
|
Hom |
YH |
|||
|
Lifting qhov hnyav (t) |
2 |
5 |
10 |
|
|
Lifting qhov siab (m) |
9/12/15/18/20 |
9/12/15/18/20 |
9/12/15/18/20 |
|
|
Hoisting ceev (m / min) |
8(2/8) |
8(2/8) |
7(1.75/7) |
|
|
Kev khiav ceev (m / min) |
20 |
20 |
20 |
|
|
Hlau hlua hom |
specification |
6 x 37 plus 1 |
||
|
H beam orbit qauv |
20a-30c |
25a-50b |
32b-50b |
|
|
Yam tsawg kawg nkaus curvature (m) |
2/3/4/5/6 |
2.5/3/4/5/6 |
3.5/4/6/7.5/9 |
|
|
Hoisting lub cev muaj zog |
Hom |
ZD31-4 |
ZD41-4 |
ZD51-4 |
|
Lub zog (KW) |
3.0(3.0/0.75) |
7.5(7.5/2.0) |
13(13/3.25) |
|
|
Kev sib hloov ceev (r / min) |
1380 |
1380 |
1380 |
|
|
Tam sim no (A) |
7.6(7.6/2.3) |
18(18/5.6) |
30(30/9.4) |
|
|
khiav ceev |
Hom |
ZDY12-4 |
ZDY21-4 |
ZDY21-4 |
|
Lub zog (KW) |
0.4 |
0.8 |
0.8 |
|
|
Kev sib hloov ceev (r / min) |
1380 |
1380 |
1380 |
|
|
Tam sim no (A) |
1.25 |
2.4 |
2.4 |
|
|
Lub zog |
Peb-theem AC 380v, 50HZ |
|||
|
Ua haujlwm system |
FC =50 feem pua |
|||
Cim npe nrov: metallurgy hluav taws xob hoist
