Hydraulic Mobile Thawv Gantry Crane
I. Adout Khoom
Lub thawv ntim khoom txawb tau siv los ntawm ntau lub tog raj kheej diesel cav. Kev nqa thiab taug kev yog tswj los ntawm hydraulic system thiab tsav los ntawm hydraulic lub cev muaj zog. Lub lifting siv 203 hli txoj kab uas hla roj lub tog raj kheej, uas muaj peev xwm nqa loj, tsis tshua muaj zog siab, du thiab nyab xeeb lifting, thiab siab loading thiab unloading efficiency. Txhua pawg muaj ob lub cranes, txhua lub crane yog ib qho kev ywj pheej txav. Txhua chav ua kis las yog ob-log tsav thiab plaub-log steering. Lub kaum sab xis siab tshaj plaws tuaj yeem ncav cuag 110 degrees. Nws tuaj yeem paub lub kauj thiab txhais lus ntawm txhua lub kaum sab xis, muaj lub vojvoog tig me me, thiab yooj yim thiab hloov tau los ua haujlwm; ob leeg cov lus tsa suab tuaj yeem khiav dawb, thiab qhov kev ncua deb tuaj yeem hloov kho arbitrarily, ua rau nws haum rau lub thawv hoisting ntawm ntau yam specifications.
II. Technical Data
|
Max. lifting ceev |
1.8m / min |
|
Tuag hnyav |
8,8t ua |
|
Lub cev muaj zog / Rated ceev |
37/2650 Kw/r/min |
|
Max. lub zog |
Ntau dua lossis sib npaug rau 148/1800-1900 Nm/r/min |
|
Max. taug kev ceev |
25m / min |
|
Lifting roj tank txoj kab uas hla |
Φ203 hli |
|
Steering roj tank txoj kab uas hla |
Φ75 hli |
|
Hydraulic lub cev muaj zog torque |
1 633nm |
|
Hydraulic motor ceev ntau yam |
6-400 r/min |
|
Tsav tsheb txoj kab uas hla |
Φ500 hli |
|
Min. av clearance |
80 hli |
III. Qhov zoo
1. Txais steel qauv lub ntsiab nqaj nrog lub peev xwm loj;
2. dav log puag, zoo stability, thiab siab mobile ua hauj lwm efficiency;
3. Yooj yim los tswj, haum rau ntau qhov chaw ua haujlwm, txo cov nqi zog.
V. Pob
